Semi-Automatic Cement Compression & Flexure Testing Machines (Motorized)

Name: Semi-Automatic Cement Compression & Flexure Testing Machines (Motorized)
Brand: SUBITEK
Price: 120000.0 INR
Availability: InStock

Price 120000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Semi-Automatic Cement Compression & Flexure Testing Machines (Motorized) Specification

Operating Voltage
230V 10%, 50 Hz

Interface Type
Manual lever with digital readout

Resolution
0.01 kN

Max Height
Approx. 1000 mm

Hardness
Abrasion and corrosion resistant finishing

Specimen Size
Cubes: 70.6 mm, Prisms: 40 x 40 x 160 mm

Measuring Range
Up to 200 kN

Equipment Type
Cement Compression & Flexure Testing Machine

Port Size
Standard lab output port

Number of Specimens
Single at a time

Features
Sturdy construction, semi-automatic operation, motorized loading, safety features

Humidity
Up to 90% RH (non-condensing)

Frequency
50 Hz

Application
Testing compressive and flexural strength of cement mortar specimens

Test Range
Up to 200 kN for compression, 15 kN for flexure

Accuracy
1% of indicated load

Response Time
<1 sec

Power Supply
230V AC, 50 Hz

Display Type
Digital (LCD)

Automation Grade
Semi-Automatic

Mounting Type
Floor mounted

Temperature
5C to 40C operating

Usage
Laboratory testing for cement, mortar strength evaluation

Capacity
200 kN (Compression), 15 kN (Flexure)

Machine Weight
Approx. 250 kg

Test Speed
50 mm/min (adjustable)

Test Width
165 mm

Test Stroke
Up to 75 mm

Control Mode
Semi-Automatic, Motorized

Piston Diameter
100 mm

Cross Head Adjustment
Manual screw adjustment

Pump Type
Hydraulic, Motor Driven

Frame Material
High-grade steel with epoxy coating

Packaging Type
Wooden crate for safe transport

Oil Reservoir Capacity
5 liters

Load Indication
Digital with peak hold facility

Safety Features
Overload and over-travel protection

Noise Level
Less than 60 dB

Semi-Automatic Cement Compression & Flexure Testing Machines (Motorized) Trade Information

Minimum Order Quantity
1 Piece

FOB Port
COIMBATORE

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Sample Available
No

Packaging Details
COTTON BOX

Main Export Market(s)
Asia, Africa

Main Domestic Market
All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

About Semi-Automatic Cement Compression & Flexure Testing Machines (Motorized)

Specification:

Semi Automatic Cement Compression & Flexural Testing Machines (Motorized) having single and double testing chamber are designed for reliable and consistent testing of mortar samples. Thesecompression and flexure testers are the results of continuous applications and research studies to upgrade the machines with the latest technologies and conform with current standards.These testers also meet the requirements of CE norms for safety and health of the operator.
Semi-Automatic cement compression and flexure testing machines allow operators who have minimal experience to perform the tests.
Semi-Automatic cement compression and flexure testing machines consist of a very rigid two column single or double chamber frame, hydraulic powerpack and data acquisition system LPI.
Compression and flexure jigs, distance pieces, and also removable transparent front-rear safety doors (should be factory installed) should be ordered separately.

Power Pack
The Motorized (Semi-Automatic) Power Pack, controlled by a pressure rate control valve, is designed to supply the required oil to the load frames for loading. The power pack can load different frames with required pace rates. A rapid approach pump is supplied as standard. The power pack is equipped with a safety valve (maximum pressure valve) to avoid machine overloading.

Dual Stage Pump
Low pressure gear pump
High pressure durable variable output pump
On the dual stage pump, high delivery low pressure gear pump is used for rapid approach, while low delivery high pressure durable variable output pump is used for test execution. Rapid approach property of the machine shortens the time interval from the piston starts moving until the upper platen touches to the specimen and helps to save a great amount of time in case of numerous specimens are going to be tested.

Motor
Dual pump is driven by an AC motor
220 V (110 V), 50-60 Hz single phase and 0.55 kW

Distribution Block
A distribution block is used to control the oil flow direction supplied by the dual stage pump which has the safety valve and pressure relief valve mounted upon it.
Safety valve (maximum pressure valve)
Pressure relief valve

Oil Tank
The tank (20 L capacity) includes enough oil to fill the mechanism which pushes the ram during the test. The level and oil temperature can be seen on the indicator fitted to the tank. Hydraulic motor oil number 46, must be used in the tank.

LPI
LPI Battery Operated Digital Readout Unit has been designed to use with load cells or pressure transducers on different material test applications.
Real time numeric display of load and load rate
1 channel with two different calibration table (can be used for 2 sensors)
Peak hold property Multi-point calibration Serial port for PC or printer
Can operate with 2 x AA batteries Easy preload zeroing 7 keys keyboard

Safety Features
Maximum pressure valves to avoid machine overloading
Piston travel limit switch

Advanced Testing Technology for Reliable Results

Our semi-automatic machine delivers consistent, accurate compression and flexure test results for cement mortars, utilizing a digital LCD interface and high-grade steel framework. This ensures not only precision but also long-term durability and resistance to abrasion and corrosion-meeting the needs of modern laboratories.

Safety and Ease of Operation with Smart Features

Outfitted with overload and over-travel protection, the machine guarantees safe testing procedures. The noise level remains below 60 dB, and the manual lever, motorized loading, and peak-hold digital readout enhance operational efficiency while safeguarding the operator.

Flexible and Versatile Laboratory Performance

With a test speed up to 50 mm/min (adjustable) and compatibility with both cubes and prisms, the equipment accommodates a spectrum of cement testing requirements. It operates effectively within 5C to 40C and up to 90% relative humidity, making it suitable for diverse laboratory environments.

FAQ's of Semi-Automatic Cement Compression & Flexure Testing Machines (Motorized):

Q: How does the machine ensure accurate and repeatable cement compression and flexure tests?

A: The machine utilizes a high-precision digital LCD display with a resolution of 0.01 kN and 1% accuracy, a stable motorized hydraulic loading system, and a robust high-grade steel frame. This ensures every cement mortar test is both reliable and consistent.

Q: What safety features does this testing machine include?

A: Safety features include overload and over-travel protection mechanisms, which prevent accidental exceeding of testing limits and safeguard both the operator and machine during operation.

Q: When is it recommended to use this semi-automatic machine in a laboratory?

A: This machine is ideal for laboratories that routinely evaluate the compressive and flexural strength of cement mortars-especially when precision, efficient digital load indication, and operator safety are required.

Q: Where can the machine be installed and what are its power requirements?

A: It is floor-mounted and designed for standard laboratory installation, requiring a power supply of 230V AC (10%), 50 Hz, ensuring compatibility with most Indian laboratory settings.

Q: What is the process for conducting a test using this equipment?

A: To operate, mount the cement specimen, manually adjust the cross head, set the desired test speed, and initiate the hydraulic motorized loading using the lever. The digital display shows real-time and peak loads, providing clear, immediate results after each test.

Q: How does the machine accommodate different specimen sizes and test types?

A: It supports single specimens at a time, specifically 70.6 mm cubes and 40 x 40 x 160 mm prisms, with selectable test ranges up to 200 kN for compression and 15 kN for flexure, enabling a broad range of cement strength analyses.

Q: What are the main benefits of using this type of cement testing machine in laboratory settings?

A: Benefits include high accuracy, semi-automatic operation for ease, digital peak load indication, versatile testing speeds, and superior construction for extended durability. Its safety and efficient design optimize laboratory workflows and results.
