Verification Of Flatness, Perpendicularity, Straightness And Dimension Of Moulds And Specimens

Send Inquiry

Request To Call Back

Verification Of Flatness, Perpendicularity, Straightness And Dimension Of Moulds And Specimens

Price 110000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Verification Of Flatness, Perpendicularity, Straightness And Dimension Of Moulds And Specimens Specification

Max Height
150 mm

Operating Voltage
Not applicable (manual)

Automation Grade
Manual

Resolution
0.01 mm

Response Time
Instantaneous

Number of Specimens
Up to 4 at a time

Humidity
Up to 80% RH (Non-condensing)

Accuracy
0.02 mm

Measuring Range
0 - 200 mm

Display Type
Analog/Digital Dial Gauge

Mounting Type
Bench/Table top

Application
Flatness, perpendicularity, straightness and dimension verification of moulds and test specimens

Power Supply
Not required (Manual Operation)

Temperature
10C to 40C

Equipment Type
Dimensional Measurement Device

Features
Portable, simple operation, robust construction

Test Range
0 - 200 mm

Specimen Size
Various, up to 150 x 150 x 150 mm

Usage
Laboratory/Industrial

Machine Weight
Approx. 10 kg

Test Speed
Manual

Test Width
Up to 150 mm

Test Stroke
100 mm

Control Mode
Manual

Packing Type
Protective Carry Case

Repeatability
0.01 mm

Compliance Standards
IS: 10086, IS: 516, ASTM C109

Material of Construction
Stainless Steel / Hardened Alloy Steel

Dimensions (LxWxH)
300 x 150 x 100 mm

Calibration Interval
12 months recommended

Gauge Type
Straight Edge/Dial Gauge

Finish
Matte/Polished

Accessories Supplied
Calibration certificate, dial gauge, instruction manual

Verification Of Flatness, Perpendicularity, Straightness And Dimension Of Moulds And Specimens Trade Information

Minimum Order Quantity
1 Piece

FOB Port
COIMBATORE

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Sample Available
Yes

Packaging Details
COTTON BOX

Main Export Market(s)
Asia, Africa

Main Domestic Market
Andhra Pradesh, Bihar, Chandigarh, All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Haryana, Himachal Pradesh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, West Bengal, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand

About Verification Of Flatness, Perpendicularity, Straightness And Dimension Of Moulds And Specimens

Specification:

The appendix of EN 12390-1 Standard calls for a set of instruments to be used for dimensional and tolerance verification of the mould and the specimens got from the same.

ZI 2023A Go-Not Go Gauge
For 100 & 150 mm cube moulds

ZI 2023B Rule
Rule straightedge, 300 mm long

ZI 2023C Feeler Gauge
Comprising a set of strips from 0.05 to 0.50 mm, with blade 100 mm long

ZI 2023D Rule Right Angle
Steel made, 150x100 mm, rectangular section

ZI 2023E Digital Vernier Caliper
0-200 mm x 0.01 mm. Readings in mm and inches

Reliable Dimensional Measurement for Moulds and Specimens

This equipment ensures dependable measurement for flatness, straightness, perpendicularity, and dimension verification of moulds and test specimens. Its sturdy stainless steel or hardened alloy steel construction provides excellent resistance to wear and corrosion. The matte or polished finish enhances ease of cleaning, making it ideal for repeated industrial and laboratory use. High repeatability and accuracy meet stringent compliance requirements for quality assurance.

Manual Operation for Hassle-Free Testing

The measurement device operates without electricity, utilizing a manual dial gauge for both analog and digital readings. No power supply is required, enabling usage in various settings. The device supports up to four specimens at a time with a test range of 0 - 200 mm. Portable and simple in operation, it is easily mounted on a bench or tabletop for convenient access during testing procedures.

FAQ's of Verification Of Flatness, Perpendicularity, Straightness And Dimension Of Moulds And Specimens:

Q: How is flatness, perpendicularity, and straightness assessed using this device?

A: This equipment utilizes a straight edge or dial gauge to manually measure the specimen's dimensions. By aligning the specimen with the reference surface and using the gauge, users can verify whether the flatness, perpendicularity, and straightness meet specified standards.

Q: What materials are used in the construction of the measurement device?

A: The device is constructed from stainless steel or hardened alloy steel, providing durability, corrosion resistance, and long-term reliability. These materials ensure consistent measurement performance even under frequent use.

Q: When should the calibration of the device be performed?

A: It is recommended to calibrate the device every 12 months to maintain accuracy and compliance. A calibration certificate is supplied initially, and subsequent calibrations should follow the recommended interval or as required by laboratory protocols.

Q: Where can this dimensional measurement device be used?

A: It is suitable for laboratories and industrial environments throughout India, including facilities operated by dealers, manufacturers, exporters, and suppliers. Its protective carry case makes it portable and easy to transport between testing sites.

Q: What is the process for using the device to verify a specimen?

A: Users mount the device on a bench or tabletop, place the specimen, and manually operate the dial gauge to measure flatness, straightness, perpendicularity, and dimensions. Immediate results are displayed on the gauge for instant evaluation.

Q: What are the benefits of using this device for dimensional verification?

A: Benefits include high measurement accuracy (0.02 mm), instant response time, portability, simple manual operation, and robust construction. Meeting IS and ASTM standards assures reliable quality assessment for moulds and test specimens.
