Marsh Cone Apparatus

Name: Marsh Cone Apparatus
Brand: SUBITEK
Price: 6500.0 INR
Availability: InStock

Price 6500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Marsh Cone Apparatus Specification

Measuring Range
Typically 3040 seconds/litre for water

Test Range
3040 seconds for standard 1 litre water flow

Power Supply
Not Required (Gravity-Based)

Resolution
1 second (timing by stopwatch)

Response Time
Instantaneous on liquid flow

Temperature
Ambient

Specimen Size
1 litre Sample Capacity

Number of Specimens
One at a time

Features
Lightweight, corrosion-resistant, easy to clean

Max Height
Approx. 500 mm

Port Size
Bottom Orifice Opening ~4.7 mm

Application
Measurement of viscosity/flow time of cement grout, drilling mud or slurry

Equipment Type
Funnel-Type Viscosity Measuring Apparatus

Accuracy
1 second

Automation Grade
Manual

Mounting Type
Tabletop or hand-held

Humidity
Ambient

Display Type
N/A (Stopwatch or visual observation)

Usage
Laboratory or field viscosity measurement

Capacity
Approx. 1 litre

Machine Weight
Approx. 2.5 kg

Test Speed
Manual (Gravity Flow)

Test Width
Standard Funnel Diameter 4.7 mm at Bottom Opening

Control Mode
Manual

Material of Construction
High-grade Aluminum / Plastic Funnel with Stainless Steel or Brass Orifice

Sample Collection Accessories
Beaker or Graduated Cylinders (optional)

Funnel Top Diameter
Approx. 150 mm

Finish
Smooth, Corrosion-resistant

Funnel Shape
Conical

Stopwatch Provided
Optional (For precise time measurement)

Cleaning Method
Easily detachable parts for thorough cleaning

Complies With Standard
API RP 13B, IS 14343, ASTM D2419

Marsh Cone Apparatus Trade Information

Minimum Order Quantity
1 Piece

FOB Port
COIMBATORE

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Sample Available
No

Packaging Details
COTTON BOX

Main Export Market(s)
Asia, Africa

Main Domestic Market
Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Arunachal Pradesh, Chhattisgarh, Punjab, Assam, Delhi, Andaman and Nicobar Islands, Dadra and Nagar Haveli, Sikkim, Tamil Nadu, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

About Marsh Cone Apparatus

Specification:

Marsh Cone Apparatus, also known as Marsh Viscosity Cone or Marsh Funnel, is used to find out viscosity of bentonite slurry and similar material. The marsh cone is 6 inch in diameter at the top and 12 inch long, and tapers to join a tube 2 inch long and 3/16 inch inside dia. The capacity of the funnel is 1500cc. Time in seconds required to flow out 1000cc of slurry from cone is measured as funnel viscosity of the material.

Marsh Funnel Viscosity Test is the most preferred test to measure the viscosity of drilling fluid. Please watch the below video for an easy demonstration of Viscosity test using Marsh Cone Apparatus.

Reliable Construction and Easy Maintenance

Manufactured from high-grade aluminum or plastic alongside stainless steel or brass for the orifice, the Marsh Cone Apparatus offers a sturdy and corrosion-resistant build. The smooth finish and detachable components facilitate thorough cleaning after every use, ensuring longevity and reliable results in both laboratory and field environments.

Optimal Performance for Accurate Viscosity Measurements

Designed for manual operation, the apparatus measures flow time and viscosity of cement grout, drilling mud, or slurry without requiring external power. Its gravity-based operation, precise funnel dimensions, and optional stopwatch enable highly accurate viscosity assessments, making it an essential tool for dealers, manufacturers, and suppliers.

Versatile Application Settings

The Marsh Cone Apparatus suits tabletop or hand-held mounting and can be used in various settings, including laboratories and field operations. It is widely deployed by exporters, fabricators, and traders for standardized viscosity testing procedures, ensuring consistent product quality and compliance with international standards.

FAQ's of Marsh Cone Apparatus:

Q: How is the Marsh Cone Apparatus used for viscosity measurement?

A: Fill the funnel with the specified 1 litre sample and allow gravity flow through the 4.7 mm orifice. Measure the time taken for the liquid to drain using a stopwatch (optional) for precise timing and determine the viscosity based on the flow duration.

Q: What materials are used in the construction of the Marsh Cone Apparatus?

A: The apparatus is constructed from high-grade aluminum or plastic for the main body, with options for stainless steel or brass for the funnel orifice, ensuring durability and corrosion resistance in various environments.

Q: When should a stopwatch be used with this apparatus?

A: A stopwatch is recommended for precise time measurements during testing. It can be optionally provided to help users achieve a timing accuracy of 1 second for flow assessments, particularly crucial in standardized procedures.

Q: Where can the Marsh Cone Apparatus be deployed?

A: It is suitable for both laboratory and field settings, as its compact, lightweight design supports portability. Common users include dealers, exporters, manufacturers, and traders throughout India.

Q: What is the process for cleaning the Marsh Cone Apparatus?

A: Cleaning is straightforward as the apparatus features easily detachable parts. Simply disassemble, thoroughly rinse each component to remove sample residues, and allow to dry before reassembly.

Q: What are the key benefits of using the Marsh Cone Apparatus?

A: Key advantages include manual operation (no power required), lightweight portability, corrosion-resistant materials, compliance with international standards, and easy maintenance, making it ideal for diverse viscosity measurement needs.

Q: Who typically uses the Marsh Cone Apparatus?

A: The device is widely used by laboratories, research facilities, construction material producers, and industry professionals for inspecting grout, drilling mud, and slurry viscosity to ensure quality and performance during manufacturing or on-site applications.
