HIGH FREQUENCY VIBRATORS

Name: HIGH FREQUENCY VIBRATORS
Brand: SUBITEK
Price: 70000 INR
Availability: InStock

Price 70000 INR/ Number

Get a Price/Quote

MOQ : 1 Number

HIGH FREQUENCY VIBRATORS Specification

Rated Power
Up to 3000W

Application
Construction, Civil Engineering, Precast concrete works

Surface
Powder coated (Power pack), Smooth (Needle)

Motor Power
1.5 kW - 3 kW

MAX TIP SIZE
60 mm

Product Type
High Frequency Vibrator

General Use
Concrete compaction

Material
Heavy Duty Rubber Hose & Steel

Type
Handheld with Needle

Capacity
Based on needle size: 35mm, 40mm, 60mm

Weight (kg)
6 - 12 kg (including needle and hose)

Computerized
No

Automatic
No

Control System
Manual Start/Stop Switch

Cooling System
Air Cooled

Method
High Frequency, Internal Vibration

Voltage
220V/230V/415V, 50/60Hz

Dimension (L*W*H)
Hose length: 5 m; Needle length: 390 mm - 410 mm

Feature
Portable, High Vibration Frequency, Durable cable and hose, Easy handling

Color
Yellow (Power pack), Black (Hose & Needle)

Hose Cover Material
Abrasion resistant rubber

Vibration Frequency
12000 - 17000 RPM

Needle Diameter Options
25mm, 35mm, 40mm, 50mm, 60mm

Usage Environment
Suitable for outdoor and indoor sites

Inner Core Material
Steel Wire Reinforced

Connector Type
Fast locking with secure coupling

Protection Grade
IP44, dust and water protected

Operating Temperature Range
-10C to +40C

Starting System
Direct Power/Electric Start

Sound Level
Below 95 dB(A)

HIGH FREQUENCY VIBRATORS About

Needle Diameter	35 mm
Power Source	Electric Motor
Flexible Shaft Length	3 m
Usage	Slab
Usage	Wall
Usage	Foundation
Usage	Pile
Usage	Beam
Usage	Column
Material	Mild Steel
Phase Type	Single
Diameter	1.5mm
Weight	6 kg
Drive Mode	Electric

Our range of Imported Concrete Needle Vibrators finds their application in High volume waste generators and companies with large quantities of heavy wood crates, skids, and drums. Owing to our industry experience, we have been able to manufacture and supply a range of Imported Concrete Needle Vibrators, which is widely demanded in the construction industry. It finds application in compaction of the top layer of earth.Our range can be customized according to the specifications of our clients and is also available in different dimensions.

Features:

Excellent functionality
Sturdy construction
High performance
Handy needle Vibrator.
0.800 W immersion type electric Handy motor.
1.5 Meter 35 Mm diameter Needle.

High Performance Vibration for Superior Concrete Quality

Delivering 12,000-17,000 RPM, these vibrators guarantee thorough concrete compaction, reducing air pockets and voids. The strong steel-reinforced hose and robust heavy-duty components are tailored to withstand challenging construction environments, ensuring problem-free operation over long hours. Their efficient internal vibration mechanism supports both small and large-scale projects.

Durability and Protection in Every Detail

With an IP44 protection grade, these vibrators are dust and water resistant, making them ideal for challenging site conditions. The abrasion-resistant rubber hose and powder-coated power pack further heighten durability, while the secure fast-locking connector facilitates safe, quick installation and use. Engineered for reliability, these vibrators maintain high performance across variable temperatures.

Versatile, User-Friendly Design

Suitable for outdoor and indoor construction sites, the vibrators feature an easy-to-use manual start/stop switch and direct electric power start. Multiple hose and needle size options provide flexibility for different job requirements. Portable and lightweight, they streamline handling and reduce operator fatigue, making them an excellent choice for contractors and construction professionals.

FAQ's of HIGH FREQUENCY VIBRATORS:

Q: How do high frequency concrete vibrators enhance concrete strength and quality?

A: These vibrators operate at 12,000-17,000 RPM, producing powerful internal vibrations that remove trapped air, minimize voids, and densely compact the concrete. This improves structural integrity, durability, and surface finish in construction or precast projects.

Q: What is the recommended usage environment for these vibrators?

A: They are designed for both indoor and outdoor sites, with IP44 water and dust protection and an operating temperature range of -10C to +40C. This makes them suitable for use in a variety of weather and environmental conditions found on construction sites.

Q: How do I choose the right needle diameter for my project?

A: Needle diameter options (25mm, 35mm, 40mm, 50mm, 60mm) allow you to select based on the size of concrete elements and compaction depth needed. Larger needles cover areas more quickly, while smaller diameters are ideal for narrow or heavily reinforced zones.

Q: What is the process for starting and operating the vibrator?

A: The vibrator features a direct electric start and a manual start/stop switch for straightforward control. Simply connect the device to an appropriate power source (220V/230V/415V, 50/60Hz), securely attach the needle using the fast-locking connector, and use the manual switch to operate.

Q: What are the primary benefits of the abrasion-resistant rubber hose and steel wire reinforced core?

A: The abrasion-resistant rubber hose, reinforced with steel wire, ensures flexibility, longevity, and resistance to wear, even in demanding construction conditions. This enhances safety, reliability, and reduces maintenance needs for users.

Q: Where can these high frequency vibrators be used?

A: They are suitable for construction, civil engineering, precast concrete works, and related applications. The equipment is ideal for contractors, builders, and operators handling concrete compaction on various scales and is distributed, supplied, or retailed throughout India.

Q: What safety features do these vibrators have?

A: With a sound level below 95 dB(A), IP44 ingress protection, reliable air-cooling, and a robust manual switch, these vibrators are engineered for user safety and comfort. Their ergonomic and portable design also reduces operational fatigue and enhances device control.
